STÄRKEN AAC WALL PANELS
STÄRKEN AAC Wall Panels are reinforced AAC, available in various edge profiles such as standard square, chamfered, tongue and groove or a combination of any of these edge profiles. Panel installation incorporates special brackets secured to structural members such as beams/ columns/ slabs to provide wall lateral stability.
Wall panels are typically used in non-residential buildings such as hospitals, universities, schools, factories, warehouses, shopping malls, e.t.c.
STÄRKEN AAC Wall Panels can be installed onto buildings of reinforced concrete or steel structure.
Packaging
| Length(mm) | Height (mm) | Thickness (mm) | General Usage |
| 600 x 6000 | 600*300mm, 400mm and 500mm available upon request. | 75, 100, 125, 150, 175, 200 | All wall panels are applicable for infill walls & load-bearing walls. |
Note :
1. The above information may subject to change.
2. Do not use the above information for calculating the transportation weight and volume.
Properties:
Modulus of Elasticity
2,190 MPa
Compressive Strength: 3.5 MPa
Thermal Conductivity: 0.172 W/m.K
Density: Dry 550 kg/m3
Working Density: 780 – 820 kg/m3
